| Product model | TZ180XS015-1 | Rated voltage (VDC) | 292 |
| Cooling method | Water cooling | Rated power (kW) | 22 |
| Back EMF (Vpeak) | 503v@9700rpm | Rated torque(Nm) | 70 |
| Peak power(KW) | 57 | Rated speed (rpm) | 3000 |
| Peak torque (Nm) | 150 | Insulation class | H |
| Maximum speed (rpm) | 9700 | Dimensions (mm) | φ221*L277 |
| Protection level | IP67 | Weight (kg) | 34kg |
| Peak current (Arms) | 230 | - | - |
| Product model | TZ180XS015-2 | Rated voltage (VDC) | 336 |
| Cooling method | Water cooling | Rated power (kW) | 18 |
| Back EMF (Vpeak) | 540@1000rpm | Rated torque (Nm) | 60 |
| Peak power (kW) | 60 | Rated speed (rpm) | 2850 |
| Peak torque (Nm) | 145 | Insulation class | H |
| Maximum speed (rpm) | 9000 | Dimensions (mm) | φ210*L293 |
| Protection level | IP67 | Weight (kg) | 34kg |
| Peak current (Arms) | 200 | - | - |
